AVPro Edge Encoder; HDMI, HDMI Loop, USB, IR, RS232, Fiber & RJ45

Product Overview

The AVPro Edge MXNet 1G Evolution II Feature Encoder provides a comprehensive I/O complement for demanding rack-based AV-over-IP deployments, combining HDMI input with loop-out, USB, IR, RS-232, both fiber and RJ45 network ports, all in a single MXNet EV2 encoding endpoint. This unit is purpose-built for the MXNet Evolution II platform and is not compatible with MXNet V1 systems. Compared to the base EV2 encoder, this model is the preferred choice for installations that require simultaneous local monitoring, multi-protocol device control, and network topology flexibility. It does not include Dante audio downmixing — the separately available AVDM variant adds that capability for an additional cost.

Product Description

In a professional rack deployment, the encoder at each source location often needs to do more than simply encode video — it must also relay control signals, extend USB devices to the display end, and connect to whichever network infrastructure is available at that point in the facility. This encoder addresses all of those requirements in a single unit. The HDMI loop-out port allows a local confidence monitor to remain on the source device without a splitter, which is particularly useful in broadcast and presentation staging environments where operators need to verify the source signal independently of the distributed feed.

The dual network interface — RJ45 for standard Cat6 connections and fiber for longer or electrically isolated runs — means the same encoder model can be deployed uniformly across a facility without needing separate SKUs for different wiring conditions. IR and RS-232 ports extend source device control from the display location, while the USB port enables keyboard, mouse, or USB device extension over the IP infrastructure, supporting KVM-style workflows in command centers and control rooms.

This encoder does not include audio downmixing. Installations that need to extract and downmix embedded HDMI audio to analog or a separate audio network should consider the AVDM-designated variant, which adds that capability. For systems where audio routing is handled at the switch or DSP level, this base feature encoder provides the complete video and control I/O set without the added cost of the AVDM option.

Key Features

• HDMI Input with Loop-Out — Encodes the source signal to the network while simultaneously passing a full-quality HDMI signal to a local monitor, useful for source confidence monitoring in rack or table-top deployments.
• Dual Network Interfaces (Fiber + RJ45) — Supports both Cat6 Ethernet and fiber connectivity, allowing uniform deployment across rack positions served by either cable type.
• USB Port — Extends USB devices — including HID keyboards, mice, and USB peripherals — from the display end to the source location, enabling remote KVM control over the AV-over-IP network.
• IR Control Relay — Passes IR commands from the display location back to source devices at the encoder, allowing display-side operators to control source equipment without a separate IR extender system.
• RS-232 Serial Control — Provides a hardware serial interface for control systems that communicate with source devices via RS-232, consolidating control wiring at the encoder.
• 4K UHD 60Hz Encoding — Captures and transmits video at up to 4K/60Hz with 4:4:4 color and multi-channel uncompressed audio embedded in the IP stream.
• PoE Powered — Powered directly from the network switch, eliminating the need for a dedicated power outlet or power supply at the encoder location.
• MXNet EV2 Exclusive — Integrates into the MXNet Evolution II management ecosystem for centralized routing, EDID management, and system monitoring.

Typical Applications

• Corporate AV rack deployments where source operators need local monitor feed and KVM control
• University AV-over-IP systems with mixed fiber and Cat6 infrastructure
• Government command centers requiring RS-232 source control integrated at the encoder level
• Broadcast and production studios needing confidence monitoring at source rack positions
• Hospitality AV systems with centralized rack encoders and distributed display endpoints

Technical Specifications

Frequently Asked Questions

What is the difference between this encoder and the AVDM variant?

The AVDM variant adds audio downmixing capability, allowing the encoder to extract and convert embedded HDMI multi-channel audio into a downmixed format for separate audio distribution. This base model carries the full uncompressed HDMI audio in the IP stream but does not perform downmixing. If your installation requires audio breakout at the encoder, choose the AVDM model. The AVDM variant is priced higher to reflect that added capability.

Can this encoder be used in a system that also has MXNet V1 devices?

No. This encoder is exclusively compatible with MXNet Evolution II decoders and the EV2 management platform. It cannot communicate with or route to MXNet V1 endpoints. Mixed V1/V2 systems require separate encoders for each platform.

Can the USB port extend USB 3.0 devices?

The USB extension capability is designed for HID-class devices such as keyboards and mice. High-bandwidth USB 3.0 peripherals like external drives are not supported. Refer to AVPro Edge documentation for the complete list of supported USB device classes.

Does the fiber port require a specific transceiver or SFP?

Yes. The fiber port uses an SFP slot. Verify the required SFP module type with AVPro Edge or your distributor before ordering fiber infrastructure, as the required module type may differ based on the fiber distance and type in your installation.
