Draper Profile+ 260" CinemaScope 2.35:1 Grey XH600V – Large Format Fixed Frame Projection Screen

Product Overview

The Draper Profile+ 260" CinemaScope fixed frame projection screen (part number 254282) produces a 101.75" x 239.25" image in the 2.35:1 widescreen format, built for auditoriums, broadcast studios, and immersive presentation environments. Its Grey XH600V surface raises perceived contrast with brighter projectors, which makes this ultrawide projection screen a practical pick for commercial AV installations where house lighting stays partially on. The lightweight Profile+ frame installs at under 2 inches deep with a borderless or slim bezel finish, giving AV system designers a large-format canvas with minimal visual hardware.

Product Description

Draper's Profile+ series is a lightweight fixed frame projection screen platform designed specifically to scale to large image sizes, and the 254282 configures it in the cinematic 2.35:1 aspect ratio with a 260 inch diagonal. The extra-wide format suits panoramic and multi-source content: AV integrators frequently deploy ultrawide screens of this class for side-by-side source windows in briefing centers, immersive worship visuals, and wide-stage presentation environments. The Grey XH600V viewing surface is a grey contrast-enhancing surface that deepens blacks and preserves image punch when paired with a moderate to high-output commercial projector, helping the image hold up under ambient light better than a standard white surface. The frame finishes at less than 2" (51 mm) deep and can be ordered borderless for an edge-to-edge picture or with a 5/8" (16 mm) bezel trim for a tailored border. Installation is handled with Draper's sliding hook-and-loop attachment system, which tensions the surface evenly across the frame, and the screen ships unassembled so crews can move it through elevators, stairs, and corners before final assembly in the room. Wall brackets are included; flown brackets for suspended rigging are available from Draper on request. If you are comparing large format fixed frame screen options for a commercial deployment, see the complete Draper lineup at creationnetworks.net/collections/draper.

Key Features

• 260" Diagonal 2.35:1 Image — Provides a 101.75" x 239.25" ultrawide viewing area for panoramic and multi-window content.
• Grey XH600V Viewing Surface — Improves contrast and black levels with brighter projectors in venues with ambient light.
• Lightweight Large-Format Frame — Profile+ engineering supports large sizes without the weight of conventional fixed frames.
• Sub-2" Installed Depth — Finishes at less than 2" (51 mm) deep for a flat-panel-like profile on the wall.
• Borderless or Bezel Finish — Specify a borderless edge or a 5/8" (16 mm) bezel trim to suit the room aesthetic.
• Wall-Mount or Flown Installation — Wall brackets ship standard; flown brackets are available on request for suspended applications.
• Hook-and-Loop Surface Tensioning — Sliding attachment system delivers a flat, evenly tensioned surface and faster field assembly.
• Ships Unassembled — Simplifies transport into finished buildings and tight pathways before on-site assembly.
• 5-Year Manufacturer Warranty — Covered by Draper's five-year warranty in the United States and Canada.

Typical Applications

• Auditorium
• Broadcast studio
• House of worship
• All-hands room
• Commercial meeting space
• Multi-purpose room

Technical Specifications

Frequently Asked Questions

Why choose a 2.35:1 screen for a commercial installation?
The ultrawide format supports cinematic content and panoramic presentation layouts, and it gives AV system designers room to blend multiple projectors or place side-by-side source windows on a single surface.

Is the Grey XH600V surface right for my room?
Grey XH600V is designed for use with moderate to high-output projectors and rewards rooms where ambient light cannot be fully controlled. If your venue is fully light-controlled and projector brightness is limited, a matt white Profile+ variant may be the better match.

How does the screen arrive and who should install it?
It ships unassembled in cartons that move easily through stairs and elevators. A professional AV integration crew or experienced facilities team can assemble the frame, attach the surface with the hook-and-loop system, and hang it on the included wall brackets.

Can this screen be flown above a stage?
Yes. The Profile+ supports flown installation; request flown brackets from Draper at order time. Rigging hardware and mounting fasteners are not included.

Does a fixed frame screen require any control system integration?
No. There are no motors, low-voltage interfaces, or relays, so the screen adds zero programming load to your control system and works with any front-projection source.

What warranty applies and where do I get support?
Draper warrants the Profile+ for five years in the US and Canada. Creation Networks provides commercial AV buyers with configuration help before purchase and support after delivery.
