Draper Profile+ 230" CinemaScope 2.35:1 – Grey XH600V Fixed Frame Screen

Product Overview

The Draper Profile+ 230" CinemaScope fixed frame projection screen delivers a 2.35:1 widescreen image measuring 90" x 211.5" with a Grey XH600V contrast surface. It is built for houses of worship, auditoriums, and commercial venues where ambient light would wash out a standard white screen. As a large venue projection screen, the Profile+ installs at under 2" (51 mm) deep with a borderless finish or a slim 5/8" (16 mm) bezel trim. The lightweight frame and hook-and-loop surface attachment keep this commercial projection screen installation manageable for a standard integration crew.

Product Description

Draper part number 254280 pairs the Profile+ fixed frame with a 230" diagonal CinemaScope 2.35:1 image area and the Grey XH600V viewing surface. The grey surface helps maintain perceived contrast and black levels in spaces with windows, house lighting, or open architecture — common conditions in worship venues and multi-purpose rooms. The 2.35:1 format suits cinematic media, environmental projection, and wide edge-blended content that standard 16:9 screens crop or letterbox. Draper engineered the Profile+ frame to support large image sizes while staying lightweight, and the finished assembly stands off the wall less than 2 inches for a clean architectural appearance. The screen can be wall-mounted with the included brackets or flown with brackets available on request. With no motor or electronics, the screen needs no power circuit or control programming, simplifying AV system integration and long-term maintenance. Sliding hook-and-loop attachments pull the surface flat and taut across the frame. The mullion-less frame design supports zero-gap alignment across multiple frames for blended arrays. The screen ships unassembled so components move easily through elevators and stairwells to the room. Explore other Draper sizes and surfaces in our Draper projection screen collection.

Key Features

• 230" CinemaScope 2.35:1 Image — A 90" x 211.5" viewing area presents true widescreen content to large audiences.
• Grey XH600V Surface — Helps preserve contrast and black levels in venues with ambient light.
• Slim Sub-2" Profile — Under 2" (51 mm) installed depth keeps the screen sleeker than a flat panel wall.
• Borderless or Bezel Trim — Choose an edge-to-edge look or a refined 5/8" (16 mm) bezel.
• Lightweight Large-Format Frame — Supports big images without heavy structural framing.
• Wall-Mount or Flown — Wall brackets included; flown brackets available on request for rigged installations.
• No Power or Control Needed — Fixed frame design integrates into any AV system without electrical work.
• Hook-and-Loop Surface Attachment — Speeds assembly and simplifies future surface replacement.
• Mullion-Less Array Alignment — Zero-gap alignment across frames supports edge-blended multi-projector designs.
• 5-Year Warranty — Draper warranty valid in the United States and Canada.

Typical Applications

• House of worship
• Auditorium
• Multi-purpose room
• All-hands room
• Government space
• Commercial meeting space

Technical Specifications

Frequently Asked Questions

When should I specify a grey screen surface?

Specify Grey XH600V when the room has ambient light you cannot fully control — windows, skylights, or house lighting that stays on during presentations. The grey base helps the projected image hold contrast under those conditions.

Is 2.35:1 the right format for my venue?

CinemaScope 2.35:1 is ideal for cinematic content, environmental worship visuals, and wide blended images. If most of your content is broadcast or presentation 16:9, consider the Profile+ HDTV variants in our Draper collection.

Can this screen be flown above a platform or stage?

Yes. The Profile+ supports flown installation; request flown brackets from Draper. Wall brackets ship standard, and mounting fasteners are not included.

Does the screen interface with control systems?

No interface is needed. As a fixed frame screen there is no motor to control, which removes wiring, programming, and a potential point of failure from the AV design.

How is the screen delivered?

It ships unassembled in compact cartons. The lightweight frame assembles on site and the surface attaches with sliding hook-and-loop fasteners for even tension.

What warranty and support come with the screen?

Draper provides a 5-year warranty valid in the U.S. and Canada, and Creation Networks supports integrators and facilities teams through specification, purchase, and after-sale questions.
