Description
(Sold as a pair)
CVS 6
The CVS 6 is a compact 240-Watt ceiling loudspeaker engineered to provide superb audio performance in both background and foreground music sound systems. Ideally suited for a wide variety of applications, from restaurants and hotels to houses of worship and businesses of all types, the CVS 6 offers the power handling, wide frequency response and low distortion more typically found in a studio reference monitor than a ceiling loudspeaker. The resulting sound is warm, with a nuanced and pristine clarity that envelopes the listener – without intruding.
Features
-
Coaxial full range ceiling loudspeaker for installation applications
-
60 Watts continuous, 240 Watts peak power
-
6" mineral loaded polypropylene driver with nitrile rubber surround for enhanced durability and long-term reliability
-
0.75" ferrofluid cooled soft dome neodymium high frequency driver
-
Wide constant directivity dispersion for optimum coverage
-
UL 1480 certified for fire-protected signalling systems
-
UL 2043 certified for air-handling spaces
-
UV and weather resistant UL 94 V-0 ABS front with plated steel fire can enclosure
-
Multiple transformer taps for 70 V and 100 V line systems or 6 Ohm direct input
-
Low insertion loss 60 W line transformer with easily accessible tapping switch
-
Semi matt white finish fits unobtrusively in any environment
-
Powder coated perforated steel mesh grille with dust protection
-
Mounting C-ring and ceiling tile rails included
-
Phoenix* connector with steel cover and strain relief clamping mechanism for fire rated cable
-
10-Year Warranty Program*
-
Designed and engineered in the U.K.
Specifications
Performance
| Frequency Response (-3 dB) (1) |
79 Hz - 21 kHz |
| Frequency Range (-10 dB) (1) |
60 Hz - 24 kHz |
| System Sensitivity (1 W @ 1 m) (2) |
91 dB (1 W = 2.45 V for 6 Ohms) |
| Nominal Coverage Angle |
90 degrees conical |
| Coverage Angle (1 kHz to 6 kHz) |
93 degrees conical |
| Directivity Factor (Q) |
7.7 averaged 1 kHz to 6 kHz |
| Directivity Index (DI) |
8 averaged 1 kHz to 6 kHz |
| Rated Maximum SPL (2) |
Average: 109 dB |
| Power Handling (3) |
Average: 60 W |
| Recommended Amplifier Power |
120 W @ 6 Ohms |
| Nominal Impedance |
6 Ohms |
| Transformer Taps (via front rotary switch) |
70 V: 60 W / 30 W / 15 W / 7.5 W / OFF & low impedance operation |
TRANSDUCERS
| Low Frequency |
150 mm (6.00") mineral loaded polypropylene ICT™ |
| High Frequency |
19 mm (0.75") |
PHYSICAL
| Enclosure |
Back Can: Zinc plated steel |
| Safety Features |
Safety ring located at rear of enclosure for load bearing safety bond |
| Clamping Design |
Security toggle clamp |
Back Can Options
| Cable Entry Options |
Cable clamp & squeeze connector for conduit up to 22 mm |
| Connectors |
Removable locking connector with screw terminals with “loop through” facility |
| Safety Agency Ratings |
UL-1480, UL-2043, CE |
| Hole Cutout Diameter |
250 mm (9.84") |
| Dimensions Bezel diameter |
279.5 mm (11.01") |
| Front of ceiling to rear of back can |
246.5 mm (9.70") |
| Front of ceiling to top of safety loop |
258.5 mm (10.18") |
| Net Weight (ea) |
5.7 kg (12.6 lbs) |
| Included Accessories |
C Ring, tile bridge, paint mask, cutout template, grille |
| Optional Accessories |
Plaster (mud) ring |
