Tannoy PCI 45DC Premium 3-Way Dual Concentric Ceiling Loudspeaker - TA-PCI 45DC

Tannoy SKU: TA-PCI 45DC
No reviews
Price:
$619.00

Description

 Designed to fit seamlessly into your world, the Tannoy PCI series is the perfect premium loudspeaker for modern living. Discover a beautiful blend of innovative technology combined with sophisticated good looks that will match any décor. State of the art driver materials and Tannoy’s Unique Dual Concentric driver technology combine to deliver music and film that is breathtakingly realistic and with phenomenal clarity.

The Tannoy PCI 45DC is a 3-way design ideal for an overhead stereo or home theatre system, the unique driver arrangement allows for use as a left, right, or center channel speaker


  • Premium, high-definition loudspeaker for ceiling installation applications

  • 4.5" Dual Concentric driver featuring Tannoy point-source constant directivity

  • Tulip Waveguide for a smooth, uniform frequency response over a wide area of coverage unachievable with discrete, two-way designs

  • Paper cone and rubber surround provide excellent sound and high excursion linearity

  • 2 x 5" woofers for remarkably clean, clear sound and powerful bass 4.5" middle Blue Kevlar* cone with high-excursion, rubber surround for high power handling

  • 70 Watts continuous, 280 Watts peak power

  • Extremely thin bezel for discreet installation

  • Rigid diecast chassis for improved bass performance and durable application

  • Integrated single unit construction for easy installation

  • Semi matt white finish fits unobtrusively in any environment

  • Powder coated UV resistant perforated steel mesh grille with dust protection

  • Removable grille for custom painting

  • Self-aligning clamp mounting system

  • Removable Tannoy grille badge

  • Tannoy - Over 90 years of British sound heritage and innovation
Frequency response (±3 dB)

100 Hz – 20 kHz
Frequency response (-10 dB)

60 Hz – 20 kHz
Sensitivity (1 W @ 1m)

90 dB
Directivity factor (Q)

6.3 averaged 1 kHz to 10 kHz
Directivity index (DI)

8 averaged 1 kHz to 10 kHz
Power handling (IEC)
Average

70 W
Programme

140 W
Peak

280 W
Recommended amplifier power

210 W @ 8 Ω
Nominal Impedance (Lo Z)

8 Ω
Rated maximum SPL (1 m, Lo Z)
Average

108 dB
Peak

114 dB
Transformer taps

NA
Crossover point

750 Hz / 2.1 kHz
Coverage angles
500 Hz

156° horizontal, 167° vertical
1 kHz

81° horizontal, 101° vertical
2 kHz

145° horizontal, 138° vertical
4 kHz

123° horizontal, 120° vertical
Transducers
Low frequency diameter/material/type

2 x 126 mm (5") / 1 x 118.5 mm (4.5")
High frequency diameter/material/type

20.4 mm (0.8")
Physical
Enclosure
Back can

Plastic,with spraying
Baffle

Reflex loaded UL94 V-0 rated ABS
Grille

Steel, with weather resistant coating
Safety features

With a safety loop
Clamping design

Security toggle clamp
Connectors

Phoenix Contact terminal block
Dimensions (HxWxD)

353 x 353 x 199 mm (13.9 x 13.9 x 7.8")
Bezel dimensions

353x353mm (13.9"x13.9")
Mounting depth

188 mm (7.4")
Hole cutout dimensions

330.2 x 330.2 mm(13.0"x13.0")
Net weight

7.7 kg (16.9 lbs)
Packed quantity

1
Included accessories

Grille, paint mask, tool kit, screws, plain washer
