SURGEX SX-DS-154
Safeguard Digital Displays
Digital displays are a vital part of a business’s interaction with their customers. Power disturbances on video, data, and audio lines can result in pixilation, hissing/crackling sounds and error codes that render equipment inoperable—resulting in customer dissatisfaction and lost income.
- Compact Design
- Wiring fault protection
- 4 receptacle configurations
- 6’ line cord
- Mounting brackets
The MultiPak safeguards digital equipment from surges, spikes, and electrical transients that can bring business to a halt. Its 360 degrees of power protection encompass multi-stage technology, catastrophic over/under voltage shutdown, inrush current elimination, and impedance tolerant noise filtering to ensure equipment remains up and running without disruption.
The MultiPak’s analytical software monitors, collects and analyzes electrical data, allowing service teams to understand power anomalies. The software identifies the potential cause of a problem and translates that data into recommendations on how to resolve the issue.
Available in four and six receptacle configurations, the MultiPak is the clear choice to safeguard digital displays
Specifications
| Parameter |
Specification |
| Load Rating |
15A |
| Voltage Rating |
120V |
| Power Requirement (no load) |
4 W |
| EMI/RFI Filter |
|
| Normal mode (50Ω load) |
>30 dB, 80 kHz - 50 MHz |
| Common Mode (50Ω load) |
>30 dB 70 kHz - 50MHz |
| Under-Voltage Auto Shutdown |
Adjustable from 80V to 95V, or disabled. Default Disabled |
| Over-Voltage Auto Shutdown |
Adjustable from 135V to 160V. Default 150V. |
| Over-Current Auto Shutdown |
Circuit Breaker |
| Over-Temperature Auto Shutdown |
None |
| Measurement Accuracy |
|
| Voltage |
± 2% Typical product accuracy between 40V and 180V |
| Current |
NA |
| Power |
NA |
| Energy |
NA |
| Temperature |
NA |
| Network Port |
No |
| Serial Port |
Custom Serial UART |
| Temperature Sensor Input |
None |
| Auxiliary Relay Outputs |
No |
| Contact Closure Input |
No |
| Dimensions |
8.152" W x 7.272" D x 1.79" H |
| Weight |
4.1 lbs |
| Temperature Range: |
5C to 35C |
| Humidity Range |
5% to 95% R.H. Non-condensing |
| Agency Listings |
Conforms to UL Stds 1283 & 1449; Certified to CSA Std C22.2 No. 8 |
| * 1.2 x 50 microsecond industry standard combination wave surge as per IEEE C62.41 |
