Smart iQ appliance for education for SMART Board 6000 and 7000 series interactive displays - UGK-AM40-EDU
Smart iQ appliance for education for SMART Board 6000 and 7000 series interactive displays - UGK-AM40-EDU is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Smart iQ appliance for education for SMART Board 6000 and 7000 se...
Product Overview
The SMART iQ Appliance for Education (AM40) is an OPS-form-factor computing module that installs into the accessory slot of compatible SMART Board 6000, 6000 Pro, MX, 7000, and 7000 Pro series interactive displays, providing a dedicated iQ Android computing environment for education use without requiring an external computer. Once installed, it delivers one-touch access to SMART's whiteboard, browser, SMART Learning Suite applications, and wireless screen sharing from student devices. The AM40 Education variant includes software and licensing configured for K-12 and higher education deployment, distinct from the Enterprise AM40 variant.
Product Description
The AM40 iQ Appliance was introduced to address the gap between display hardware and compute capability in education settings: a SMART Board display that lacks both an OPS PC module and an iQ appliance requires a connected external computer for every use session. Installing the AM40 removes that dependency, enabling the display to function as a standalone interactive station for lesson delivery, group activity, and content review without any computer connection. The RK3399 processor (dual-core Cortex-A72 + quad-core Cortex-A53, 2 GHz) with 4 GB DDR3L RAM and 32 GB eMMC 5.1 storage provides sufficient performance for SMART's iQ software suite, web browsing, and third-party educational applications. Bluetooth 4.2 enables mobile device connectivity via QR code scanning to the SMART kapp app, allowing participants to share and annotate from their own devices. Wi-Fi 802.11 a/b/g/n/ac with 2×2 MIMO provides reliable wireless connectivity in the classroom. For displays in the Gen 5 series, a wired RJ45 Gigabit Ethernet port is available. Two USB 3.0 Type-A ports provide peripheral and storage connectivity. An HDMI 1.4 output supports connection of a secondary display. Power requirements of 12–19 VDC at 2.5–1.6A are supplied directly from the display's accessory slot. The appliance is designed for the education SKU only — the iQ Enterprise experience for 6000 Pro and 7000 Pro series displays requires the AM40 Enterprise (UGK-AM40-ENT).
Key Features
- Standalone iQ Education Experience — One-touch whiteboard, browser, SMART Learning Suite apps, and screen sharing without an external PC.
- Compatible with SMART Board 6000, MX, 7000 Series — Drop-in OPS slot installation for education-licensed SMART Board displays.
- 4 GB DDR3L RAM / 32 GB eMMC — RK3399 dual/quad-core processor for smooth iQ application performance.
- Wi-Fi 802.11ac Dual-Band — 2.4 and 5 GHz connectivity for reliable classroom wireless.
- QR Code Mobile Device Connectivity — Students connect from iOS or Android via the SMART kapp app for collaborative whiteboard participation.
- 2× USB 3.0 Type-A Ports — Peripheral and USB storage access from the installed module.
- HDMI 1.4 Output — Secondary display connection for dual-screen setups.
- 3-Year Limited Warranty — Commercial-grade warranty for education deployments.
Typical Applications
- K-12 classrooms upgrading existing SMART Board 6000 or 7000 series to standalone iQ operation
- Higher education tutorial rooms and seminar spaces
- Education facilities eliminating dedicated classroom PCs
- Bring-your-own-device classrooms leveraging QR code student connectivity
Technical Specifications
| Specification | Detail |
|---|---|
| Processor | RK3399, Dual-core A72 + Quad-core A53, 64-bit, 2 GHz |
| Memory | 4 GB DDR3L SDRAM |
| Storage | 32 GB eMMC 5.1 |
| Wi-Fi | IEEE 802.11 a/b/g/n/ac, 2×2 MIMO, dual-band 2.4/5 GHz |
| Bluetooth | 4.2 |
| Outputs | HDMI 1.4 (1920×1080) |
| USB | 2× USB 3.0 Type-A |
| Ethernet | RJ45 Gigabit (Gen 5 displays only) |
| Form Factor | OPS accessory slot |
| Power Requirements | 12–19 VDC, 2.5–1.6A |
| Power Consumption | ≤30 W |
| Unit Weight | 1 lb. 8 oz. (677 g) |
| Dimensions | 5 7/8" × 7 7/8" × 1 1/8" (14.9 cm × 20 cm × 3 cm) |
| Operating Temperature | 41–95°F (5–35°C) |
| Certifications | UL, FCC, ISED, CE, RCM, RoHS, REACH, WEEE |
| Warranty | 3-year limited equipment warranty |
Frequently Asked Questions
Which SMART Board displays does the AM40 Education work with?
The AM40 is compatible with SMART Board 6000, 6000 Pro, MX, 7000, and 7000 Pro series displays. It is not compatible with GX series displays (which use the AMG1) or newer MX-V4/V5 displays that have iQ built in.
What is the difference between AM40 Education and AM40 Enterprise?
The Education variant (UGK-AM40-EDU) is licensed for SMART Board 6000 and 7000 series education displays. The Enterprise variant (UGK-AM40-ENT) is licensed for SMART Board 6000 Pro and 7000 Pro displays and includes SMART Meeting Pro features.
Do students need to install an app?
Students scan a QR code on the display to download the SMART kapp app from the App Store (iOS 9+) or Google Play (Android 4.4.4+). After initial installation, reconnection is seamless.
Does the AM40 replace an external PC?
For iQ-based workflows (whiteboard, browser, screen sharing, SMART Learning Suite), yes. For full Windows applications, a SMART PCM module (sold separately) would be the alternative.
What warranty is included?
A 3-year limited equipment warranty is included.
