Panasonic AW-RP150GJ5 Touchscreen Remote Camera Controller
Product Overview
The Panasonic AW-RP150GJ5 is a touchscreen remote PTZ camera controller for multi-camera live production. A 7-inch touch-panel GUI, a one-hand joystick with built-in zoom rocker, and integrated SDI monitoring let a single operator frame, focus, and switch shots across a large camera count. It controls up to 200 cameras over IP and integrates into broadcast studios, houses of worship, and live event productions running Panasonic professional PTZ cameras.
Product Description
The AW-RP150 builds on the operational feedback behind earlier Panasonic controllers, adding a large touch-panel monitor and a redesigned joystick for precise single-handed pan, tilt, and zoom. The touchscreen doubles as a confidence monitor through its 3G-SDI input, so an operator can view camera output and switch to menus or settings without a separate display. Touch focus with Focus-in-Red and peaking speeds critical focus, and the 4K crop frame function lets the operator define and fine-tune cropped regions on compatible cameras such as the AW-UE150. Preset memory stores up to 100 positions with recall by speed or time, and tracing memory records camera moves for repeatable shots. Connectivity includes a 3G-SDI active through output, five RS-422 serial ports, LAN with PoE+, and two GPIO/tally connectors, while an SD card slot clones scene and system files across multiple cameras to cut on-site setup time. It is compatible with the full lineup of Panasonic professional PTZ cameras (excluding the AW-UE4), including the AW-UE150A, AW-UE160, and AW-UE100; for a more compact panel, see the AW-RP60.
Key Features
- 7-inch Touch-Panel GUI — A WVGA touchscreen consolidates menus, camera switching, and indicators, with frequently used controls on dedicated buttons.
- One-Hand Joystick — Integrated pan, tilt, and zoom on a single joystick with a built-in zoom rocker for smooth, precise moves.
- SDI Monitoring — A 3G-SDI input displays camera output on the panel, with a 3G-SDI active through output for downstream routing.
- Controls Up to 200 Cameras — Manages up to 200 cameras over IP (5 over RS-422), organized into 20 groups of 10.
- 4K Crop Frame Control — Define and adjust cropped regions on compatible cameras such as the AW-UE150 directly from the controller.
- Touch Focus and Focus Assist — Tap-to-focus with Focus-in-Red and peaking for fast, accurate focus.
- Preset and Tracing Memory — Up to 100 presets with speed/time recall, plus tracing memory for repeatable camera moves.
- PoE+ Powered — Single-cable power and control simplify permanent installs and mobile productions; 12 V DC input also provided.
- SD Card Cloning — Copy scene and system settings to multiple cameras via SD card to reduce on-location setup time.
Typical Applications
- Broadcast studio
- Auditorium
- House of worship
- Government space
- All-hands room
Technical Specifications
| Product Type | Remote PTZ camera controller |
|---|---|
| Display | 7-inch touch-panel GUI monitor (WVGA 800 x 480) |
| Connectable Cameras | 200 (IP), 5 (RS-422) |
| Camera Groups | 20 groups of 10 (10 selection buttons) |
| SDI | 3G-SDI input; 3G-SDI active through output |
| Serial Control | 5x RS-422 (RJ-45) |
| Network | 100BASE-TX with PoE+ |
| GPIO / Tally | 2x D-sub 25-pin GPIO; tally output |
| Preset Memory | 100 presets; tracing memory up to 5 min per camera |
| Storage | SDHC / SDXC card slot for settings cloning |
| Assignable Buttons | 6 hardware + up to 10 on LCD; 7-level pan/tilt speed |
| Power | 12 V DC (10.8 to 13.2 V) or PoE+ |
| Dimensions (W x H x D) | 342 x 178 x 245 mm |
| Weight | Approx. 3.2 kg (7.05 lb) |
Specifications sourced from Panasonic / vendor data. The exact list of currently supported cameras evolves with firmware and should be confirmed against the current Panasonic AW-RP150 compatibility chart.
Competitor Comparison
| Criteria | Panasonic AW-RP150 | Sony RM-IP500 | BirdDog PTZ Keyboard |
|---|---|---|---|
| Built-in Monitor | 7-inch touchscreen with SDI input | Small status display, no SDI monitor | Touchscreen on the BirdDog Comms model, no SDI input |
| Primary Camera Ecosystem | Panasonic professional PTZ (excluding AW-UE4) | Sony PTZ cameras over VISCA/IP | NDI cameras, BirdDog and third-party |
| IP Camera Capacity | Up to 200 over IP | Up to roughly 100 over IP | Scales across NDI network sources |
| SDI Connectivity | 3G-SDI in plus active through out | No SDI | No SDI |
| 4K Crop Control | Yes, on compatible cameras (e.g. AW-UE150) | Not provided | Not provided |
| Power | PoE+ or 12 V DC | External DC supply | PoE on most models |
| Preset Memory | 100 presets plus tracing memory | Preset recall, no tracing memory | Preset recall via NDI control |
Frequently Asked Questions
Which cameras does the AW-RP150 control? It works with the full lineup of Panasonic professional PTZ cameras, excluding the AW-UE4. Confirm current firmware compatibility for your specific models with Creation Networks.
How many cameras can one controller manage? Up to 200 cameras over IP, organized into 20 groups of 10, plus up to 5 cameras over RS-422.
Can I monitor camera output on the controller? Yes. The 3G-SDI input displays camera video on the 7-inch touchscreen, and a 3G-SDI active through output passes the signal downstream.
Does it speed up multi-camera setup? Yes. Scene and system files can be saved to an SD card and copied to multiple cameras, which reduces on-location configuration time for large rigs.
Can it be powered over the network? Yes. It supports PoE+ for single-cable power and control, and also accepts a 12 V DC input.
What warranty applies? The controller carries the applicable Panasonic Pro AV warranty; contact Creation Networks to confirm coverage.
