Middle Atlantic GRK-LVT24 24DP,GRK LG PERF VENT TOP
Overview
The Middle Atlantic GRK-LVT24 is a large perforated vented top panel for GRK Series racks with a 24-inch depth. With 64 percent open area, it maximizes passive convection airflow out of the rack enclosure, reducing reliance on active cooling in thermally sensitive installations.
Description
The GRK-LVT24 replaces the standard solid top on 24-inch deep GRK racks with a high-open-area perforated panel engineered specifically to facilitate natural convection. The 64 percent open area is among the highest available for GRK top panels, allowing heat generated by equipment to rise freely out of the enclosure rather than accumulating and causing thermal throttling or equipment failure. The panel fits flush with the rack's top frame and maintains the structural integrity of the enclosure.
Key Features
- 64 percent open area for maximum passive airflow
- Designed specifically for 24-inch deep GRK Series racks
- Large perforation pattern allows unrestricted convective heat escape
- Maintains full rack structural integrity
- Drop-in replacement for solid GRK top panels
- Steel construction with matching GRK finish
Typical Applications
- GRK racks housing high-heat amplifiers or power amplifiers
- AV equipment racks in venues with limited active cooling
- Network equipment enclosures relying on natural convection
- Broadcast racks where fan noise must be minimized
- Any 24-inch deep GRK installation with elevated thermal loads
Technical Specifications
| Attribute | Value |
|---|---|
| Model | GRK-LVT24 |
| Compatible Rack | GRK Series, 24-inch depth |
| Open Area | 64% |
| Panel Type | Large perforated vented top |
| Construction | Steel |
FAQ
- Will the GRK-LVT24 fit GRK racks of other depths?
- No — the LVT24 is sized for 24-inch deep GRK racks only. Middle Atlantic offers LVT panels for 30, 36, and 42-inch depths separately. Contact Creation Networks to confirm compatibility.
- Does installing a vented top compromise rack security?
- The perforations are sized to allow airflow but are not large enough to permit finger or tool access to equipment. Physical security remains intact.
- Do I need to remove hardware to swap the top panel?
- The GRK-LVT24 is designed as a direct replacement for the solid GRK top. Typical installation requires only basic hand tools.
- Is this panel compatible with blanking panels and fan trays?
- The vented top is a passive solution. If active fan trays are needed, consult Middle Atlantic's GRK fan tray accessories rather than this panel.
