Draper Scissor Lift SLX21 - 300253

Product Overview

The Draper Scissor Lift SLX21 is a heavy-duty commercial projector ceiling lift designed for large-venue AV installations where high-ceiling access and projector stability are required. Supporting up to 350 lb (159 kg), the SLX21 extends up to 21 feet (640 cm) — a practical range for auditoriums, multi-purpose rooms, and university lecture halls with mid-to-high ceiling structures. Three independent scissor assemblies deliver lateral and front-to-back stability across the full travel range, and two programmable show positions enable repeatable projection placement without manual adjustment between events.

Product Description

The SLX series is Draper's top-tier ceiling-mounted projector lift, hand-assembled and factory-tested in Spiceland, Indiana. The SLX21 addresses commercial AV installations where projectors are large and maintenance access at height is a recurring need. Three scissor sets distribute load laterally and front-to-back to reduce vibration, keeping the image stable during long-running presentations or services.

Two programmable show positions provide flexibility for venues that use the space in different configurations. Positions are memory-retentive and survive power interruptions — the lift restores to set positions automatically, requiring no technician intervention after power restoration. The SLX21 supports projectors drawing up to 12 amps and includes a built-in 115V or 240V UL-listed receptacle for direct projector power from the lift chassis.

Optional accessories include Environmental Airspace Housing for plenum-rated installations, a ceiling closure panel (white or black) for finished ceiling appearance, a ceiling finish kit with trim ring, a universal projector bracket, and factory-installed cable runs for video and control signals. Standard controls are a wall switch and service key switch; optional IR enables third-party AV control system integration.

Key Features

• 350 lb (159 kg) lifting capacity — Supports large-format commercial projectors up to 12 amps.
• 21' (640 cm) maximum extension — Suited for mid-to-high ceiling auditoriums, lecture halls, and multi-purpose rooms.
• Three-axis scissor stability — Three independent scissor sets provide lateral and front-to-back stability throughout travel.
• Two programmable show positions — Power-loss retentive; positions restored automatically after power interruption.
• Built-in projector power outlet — UL-listed 115V or 240V receptacle built into the lift chassis.
• Optional Environmental Airspace Housing — For plenum-rated ceiling installations.
• Optional ceiling closure panel — White (standard) or black to match ceiling finish.
• Factory cable integration — Video and control cables factory-routed through the lift assembly.
• Wall switch + service key standard — Optional IR for Crestron, Control4, and other AV control systems.
• 110V or 220V motor options — Domestic and international electrical compatibility.
• White or black finish — White standard; black available.
• USA manufactured — Hand-assembled and tested in Spiceland, Indiana.

Typical Applications

• Auditorium and large-format presentation spaces
• House of worship main sanctuaries
• University and higher-education lecture halls
• Government briefing rooms
• Multi-purpose and all-hands rooms

Technical Specifications

Frequently Asked Questions

What projector weight does the SLX21 support?
Up to 350 lb (159 kg), suited for large-format commercial projectors used in auditoriums and lecture halls.

Does the lift supply power to the projector?
Yes. A built-in 115V or 240V UL-listed receptacle powers the projector directly from the lift chassis.

Is it compatible with Crestron or Control4?
Optional IR control enables integration with Crestron, Control4, and most commercial AV automation platforms.

Are show positions retained after a power outage?
Yes. Programmed positions are memory-retentive and restored automatically after power restoration.

Is the SLX21 suitable for plenum-rated ceilings?
Yes, with the optional Environmental Airspace Housing accessory.

What is the warranty?
One year against defects in materials and workmanship. Contact Creation Networks for support.
