Crestron AirMedia Connect Presentation Adaptor - AM-TX3-100

Availability: Call for Availability
Crestron SKU: AM-TX3-100
No reviews
Price:
$480.00 $800.00

Description

 

Spec Sheet

The Crestron AirMedia® Connect Adaptor (AM-TX3-100) enables wireless presentation when paired with a Wi-Fi® network capable AirMedia Series 3 Receiver. Deploy the AM-TX3-100 alongside an AirMedia Series 3 Receiver in conference rooms, huddle rooms, lounges, lobbies, or almost any space to establish a productive meeting environment.

A System Solution
The AM-TX3-100 works alongside a Wi-Fi network capable AirMedia Series 3 Receiver for a complete system solution. Built-in Wi-Fi network connectivity creates a point-to-point network between the adaptor and the receiver for seamless connectivity without interruption. Easily pair up to eight adaptors to a single receiver.

Simple Connectivity
Using the integrated USB-C® cable, connect the AM-TX3-100 to a personal device for seamless wireless presentation on an in-room display. Because USB-C offers native video communication, no software installation is required on the personal device.

Rapid, High‑Resolution Presentation
After connecting the AM-TX3-100 to a personal device, share content with up to 4K30 resolution in seconds. Use the LED backlit, capacitive touch buttons to start, stop, or pause the presentation at any time.

Enterprise-Grade Security
The AirMedia platform is an enterprise-grade solution that can be deployed across hundreds of spaces, and set up easily using just a web browser, Crestron Fusion® software, or the XiO Cloud® service. It employs standard network security protocols, including 802.1x network access control, Active Directory® authentication, and AES content encryption to protect privacy and ensure compliance with your organization’s IT policies.

  • Connects to a personal device using an integrated USB‑C® connector
  • Shares content up to 4K30 resolution within seconds of connecting to a personal device
  • Wirelessly pairs with a Wi‑Fi® network capable AirMedia Series 3 Receiver
  • Pair up to eight AirMedia Adaptors with a single Wi‑Fi® network capable AirMedia Series 3 Receiver
  • Includes backlit capacitive touch buttons for convenient content sharing control
  • No software or driver installation required

Crestron AM-TX3-100

Communications
Wi‑Fi WiFi 6 (802.11ax)
USB USB 2.0
OS Support Windows 10, Windows 11, macOS® 11 or newer
Video
Input Signal Types DisplayPort™ Alt over USB-C
Output Signal Types Network stream over Wi‑Fi, received by a paired AirMedia Series 3 receiver (AM-3000-WF, AM‑3100‑WF or AM‑3200‑WF)
Maximum Output Resolution 3840x2160@30Hz (2160p30);
Output resolution is determined by the HDMI® output on a paired AirMedia Series 3 receiver (AM-3000-WF, AM‑3100‑WF or AM‑3200‑WF)

NOTE: All video inputs will be scaled to the selected HDMI output resolution.
Audio
Input Signal Types DisplayPort Alt over USB-C
Output Signal Type Network stream over Wi‑Fi, received by a paired AirMedia Series 3 receiver (AM-3000-WF, AM‑3100‑WF or AM‑3200‑WF)
Input/Output Format 2 channel LPCM
Connectors
USB (1) USB‑C connector, male
Controls and Indicators
Status Ring RGB LED Ring indicates device status
Screenshare (1) RGB backlit capacitive touch button controls screensharing functions
Auxiliary (1) RGB backlit capacitive touch button (for future use)
Power
USB Powered via USB-C connection to personal device
Power Consumption 2.5 W (typical)
Environmental
Temperature 32° to 104°F (0° to 40°C)
Humidity 10% to 90% RH (non‑condensing)
Heat Dissipation 8.5 BTU/hr
Construction
Chassis Plastic, black finish
Mounting Freestanding
Dimensions
Height 2.95 in. (75 mm)
Width 0.66 in. (17 mm)
Depth 7 in. (178 mm) including cable
Weight
3.17 oz (90 g)
Compliance
Regulatory Model: M202018002
UL® Listed for US & Canada, CE, IC, FCC Part 15 Class B digital device
