Atlona Avance 4K HDMI Transmitter and Receiver HDBaseT Extender Kit - AT-AVA-EX70-2PS-KIT

Atlona SKU: AT-AVA-EX70-2PS-KIT
No reviews
Price:
$325.00

Description

Extend your transmission of HDMI DCI/UHD 4K60 video signals up to 130' using the Avance 4K HDMI Transmitter and Receiver HDBaseT Extender Kit from Atlona. The kit includes a transmitter, receiver, two power supplies, and surface mounting hardware to fit these compact units easily into your A/V environment in a classroom, conference room, or event space.

The transmitter inputs up to DCI/UHD 4K video via HDMI from a computer, Blu-ray, camera, or other HDMI source, and it sends the signal via HDBaseT over Cat 6/6a cable up to 130' to the receiver. If transmitting up to 1080p60 video resolution, you can send the signal up to 230' over Cat 6/6a. The units also support embedding up to 24-bit 192 kHz audio.

  • TX/RX HDMI-over-HDBaseT Extender Set
  • Extend DCI/UHD 4:2:0 Video up to 130'
  • Extend 1080p60 HDMI Video up to 230'
  • Connect 4K and HD Sources and Displays
  • EDID Management, HDCP 2.2 Compliant
General Information
Manufacturer Atlona Technologies
Manufacturer Part Number AT-AVA-EX70-2PS-KIT
Manufacturer Website Address http://www.atlona.com
Brand Name Atlona
Product Name Avance 4K/UHD HDMI Extender Kit
Product Type Video Extender Transmitter/Receiver
Technical Information
Connectivity Technology Wired
Number of Input Devices Supported 1
Number of Output Devices Supported 1
Maximum Operating Distance 229.66 ft
Video
Graphics Modes 4K UHD
Maximum Video Resolution 3840 x 2160
Interfaces/Ports
Network (RJ-45) Yes
HDMI In Yes
HDMI Out Yes
USB Yes
Number of Network (RJ-45) Ports 1
Number of USB Ports 2
Number of HDMI Inputs 1
Number of HDMI Outputs 1
Media & Performance
Media Type Supported Twisted Pair
Physical Characteristics
Transmitter Height 0.93"
Transmitter Width 4.20"
Transmitter Depth 2.95"
Receiver Height 0.93"
Receiver Width 4.20"
Receiver Depth 2.95"
Transmitter Weight (Approximate) 7.05 oz
Receiver Weight (Approximate) 8.11 oz
Miscellaneous
Package Contents 1 x Transmitter Unit 1 x Receiver Unit
Environmentally Friendly Yes
Environmental Certification RoHS
