MaxHub UC M40 Multiple 4 camera 360 conference degree capable 360 FOV 4K Resolution

Be seen. Be heard. Be amazed by the all-in-one conference camera that tracks every face or follows every word in small to medium-sized spaces. Small enough to fit in the palm of your hand, the UC M40 combines 4-lens precision with intelligent speaker tracking for a true 360deg; immersive experience naturally. The coverage is expansive. The experience is extraordinary.Style meets substance in a sleek metal design that combines easy portability with robust capability and intuitive controls and displays. From one-tap mode switching to the LED voice location indicator, the UC M40 turns even challenging spaces into productive meeting places.The UC M40 integrates a 360deg; camera, speakers, and voice-tracking microphones in a design as portable as it is stylish. Just as impressive: The camera requires no external devices or time-consuming setup efforts. User satisfaction is built right in.MAXHUB collaboration technology is compatible with all popular video conferencing applications. Whichever platform you prefer, the UC M40 will be your conference camera of choice.Plug in the USB and start your meeting. Operating in Standalone Mode, the UC M40 provides full performance right out of the box. Therersquo;s no software to install, no complicated settings to configure. Choose your collaboration scenario with a simple tap, and the intelligent speaker-tracking technology and 360deg; camera will take it from there.

Features

• Compact design. Expansive versatility.
• 360° coverage. Minimal distortion.
• 360° panoramic wide-angle view
• 5MP 4-lens camera
• All in the palm of your hand.
• Towering performance on every platform.
• Standalone Mode- Ready when you are.
• AI auto-tracking technology
• Two-direction simultaneous voice tracking
• Professional Mode - For precision performance.
• Towering performance on every platform.
• Package Contents:
• UC-M40 Camera
• Power Adaptor
• USB Cable
• User Guide

Specs

MAXHUB UC-M40 Specifications:

• Camera:
  • Image Sensor: 1/2.7" CMOS
  • Effective pixels: 5M
  • Maximum frame rate: 2560H x 1440V @30fps
  • Number of Lens: 4
  • Focal length: 2.49mm
  • Aperture: 2.5
  • Field of view: 140°( D ) , 111°( H ) , 85°( V )
  • Output resolution: MJPG:4992*928@30、1920*1080@30、1280*720@30、640@360@30; YUY2:640*360
  • Video format: MJPG/YUY2
• Microphone:
  • Quantity: Built-in 4 array omnidirectional microphones
  • Signal to noise ratio: 65 dB
  • Pickup range: 5m(radius)
  • Pickup angle: 360°
  • Response frequency: 200Hz to 8 kHz
• Speaker:
  • Quantity: 1
  • Rated power: 3W
  • Sound pressure level: 75dBSPL@1m,1kHz
  • Signal to noise ratio: ≥75 dB
  • Distortion: ≤5%
  • Cavity volume: 0.35L
  • Frequency response range: 200Hz to 15kHz
• USB Features:
  • Operating System: Windows/Mac/Android/Linux
  • Hardware requirement: 2.4GHz Intel Core 2 Duo Processor or above, 2GB RAM or above
  • Color System / Compression: YUY2/MJPG
  • USB: USB 2.0
  • USB Audio: Build-in Mic & Speaker
  • UVC: 1.1
• Environmental Conditions
  • Operation Temperature: 0°C~40°C
  • Operation Humidity: 10%~90%RH
• Compatible Applications:
  • Support Major VC Software: ZOOM, Microsoft® Teams, Google Meet, Google Hangouts, Cisco WebEx®, RingCentral, etc.
• Power:
  • power supply: 12V 1A
  • Maximum power consumption: < 8W
• I/O ports | Buttons | Indicator:
  • DC IN: 1
  • USB Type-C(USB2.0): 1
  • Mode Button: 1 (Video layout switch)
  • Soft Button: 1 (Mute/unmute)
  • Indicators: 8 (Sound Locator), 1 (Microphone status)
• Physical:
  • Camera Dimension L×H×D: 67.6 × 67.5 × 182.3mm
  • 1pc Dimension (package)L×W×H: 235 x 165 x 91mm
  • Net Weight: 450g
• Warranty:
  • Camera: 3 years
  • Accessories: 1 year
