Sharp NP-PA1705UL 17,000-Lumen WUXGA Laser 3LCD Projector (No Lens)

Authorized Dealer

$29,936.00 $34,499.00

Shipping calculated at checkout.

Sharp | SKU: NP-PA1705UL-B

Color: Black

Product variants

Shipping Availability*

Free Ground Shipping on Most Orders Over $250.00

NEC's PA1705UL is a 16,000-lumen (Center: 17,000lm) LCD laser projector with advanced professional installation features for higher education and corporate users. With its multitude of digital inputs, connection to any computer or high definition device is possible. Enjoy design and installation flexibility with a complete line of optional motorized lenses (lens shift, focus and zoom), roll free installation capabilities. The HDBaseT input provides a single connection for uncompressed full HD digital video, audio, ethernet power and various control signals. HDBaseT Repeater allows cascading of the signal for edge-blending or stacking applications.

Features

4K Ready - Display stunning 4K 60P content using NEC’s proprietary high performance video processing/scaling chip from “Ultra HD Blu-ray” and “4K TV broadcasting” without the loss of critical details.
Learning of basic control of competitors product reducing the need for reprogramming of a control system. (call Sharp for complete list)
Integrated software applications such as AMX Beacon, Crestron Roomview, Extron XTP and PJ link allow for complete interactivity and control.
16,000-lumen (Center: 17,000lm) brightness provides brilliant images in most high ambient lighting situations.
ProAssist™ is software for controlling the projector and adjusting the projected image on the screen from a computer via a network. It allows necessary adjustments to be carried out easily when combining several projectors together to project a large screen in a classroom, meeting room, auditorium or other large space.

Specs

Display

Aspect Ratio	16X10	Screen Resolution	WUXGA 1920x1200
Maximum Resolution	4K 4096 x 2160	Brightness (typical)	16000 Lumens
Brightness (maximum)	17000 Center Lumens	Contrast Ratio (typical)	3,000,000:1 (with Dynamic Contrast)

Synchronization Range

Horizontal (Analog/Digital)	24-153kHz	Vertical	50-120Hz

Signal Compatibility/Connectivity

Supported Video Standards	NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM	SD/HD Video Signal Compatibility	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 4K
PC Signal Compatibility	VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA, Quad HD	Macintosh Signal Compatibility	Yes
Sync Compatibility	Separate Sync / Composite Sync / Sync on G	External Control	RS-232, IR, Wired Remote, HDBaseT, DDC/CI, RJ-45, USB (USB 2.0)
Input Terminals RGB1(digital): HDMI (V2.0) w/HDCP (V1.4/2.2) RGB2(digital): HDMI (V2.0) w/HDCP (V1.4/2.2) RGB3(digital): HDBaseT w/HDCP (V1.4/2.2) RGB4(digital): 3G SDI (SMPTE ST 424M / SMPTE 292M)		Output Terminals Audio Out: Stereo Mini Jack

Power Consumption (typical)

On	1035W / 855W / 0.4W / 0.15W (Normal/Silent Mode/Network Standby/Standby)	Input Current	12.8A - 5.6A
Power Requirements	100-240V AC, 50/60 Hz

Physical Specifications

Dimensions (WxHxD) Product: 23.6 x 9.4 x 19.3 in. / 599 x 238 x 490 mm External: 23.6 x 9.4 x 19.3 in. / 599 x 238 x 490 mm Shipping: 29.1 x 15.0 x 24.8 in. / 739 x 382 x 629 mm		Weight Net Weight: 63.3 lbs. / 28.7 kg Shipping: 78.3 lbs. / 35.5 kg

Environmental Conditions

Operating Temperature	32-113°F / 0-45°C	Operating Humidity	20 to 80% Humidity (Non-Condensing)
Operating Altitude	0 to 2600 m (8,500 ft)	Storage Temperature	14-122°F / -10 50°C
Storage Humidity	20% - 80% (non-condensing)	Storage Altitude	0-12,000m / 0-39,370ft (above sea level)

Limited Warranty (parts & labor)

Registered owners receive a 5-year or 20,000 hours parts and labor warranty including InstaCare next business day exchange.

Additional Features

4K Ready Motorized Lenses Manual Keystone Correction Quick power on ECO Mode Technology DiCom Simulation NaViSet Administrator 2 Quick power-off Advanced AccuBlend AutoSense ProAssist Software

Optical

Display Technology	1.0" LCD w/ MLA	Light Output(Lumens)	17,000 Lumens
Light Source Life	20,000 hours	Throw Ratio	0.53 to 0.65:1 Motorized Zoom Lens / 0.65 to 0.87:1 Motorized Zoom Lens / 0.86 to 1.25:1 Motorized Zoom Lens / 1.24 to 2.01:1 Motorized Zoom Lens / 1.98 to 3.95:1 Motorized Zoom Lens / 3.95 to 7.4:1 Motorized Zoom Lens
Projection Distance	2.17 to 262 ft. / 0.67 to 79.8m	Projector Angle	3.1 to 28.2° tele / 5.7 to 31.5° wide
Lens Zoom: Motorized Focus: Motorized F number, fnumber: (NP51ZL) F=185 to 2.2, f= 12.0 - 14.8mm, 11.7 lbs. / 5.3 kg, (NP52ZL) F=1.84 to 2.25, f= 14.4 - 19.3mm, 11.5 lbs. / 5.3 kg, (NP53ZL) F=1.8 to 2.24, f= 19.0 - 27.6mm, 11.2 lbs. / 51 kg, (NP54ZL) F=1.8 to 2.24, f= 27.7 - 44.9mm, 9.0 lbs. / 4.1 kg, (NP55ZL) F=1.84 to 2.58, f= 43.8 - 87.2mm, 11.0 lbs. / 5.0 kg, (NP56ZL) F=2.0 to 2.5, f= 49.7 to 99.8mm, 10.1 lbs. / 4.6 kg		Keystone Correction	+/- 40° horizontal, +/- 30° vertical

Mechanical

Installation Orientation	Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear	Fan Noise	43 dB normal / 37 dB slient mode
Regulations	USA UL60950-1: 2nd edition, UL 62368-1, 3rd Edition, FCC Part15 Subpart B(ANSI C63.4.2014), CAN/CSA C22.2 No.62368-1-19, 3rd Edition, ICES-003 Issue 7(ANSI C63.4-2014)	Optional Lenses	Motorized Zoom Lens 0.53-0.65 (NP51ZL) Motorized Zoom Lens 0.65-0.87 (NP52ZL) Motorized Zoom Lens 0.86-1.25 (NP53ZL) Motorized Zoom Lens 1.24-2.01 (NP54ZL) Motorized Zoom Lens 1.98-3.95 (NP55ZL) Motorized Zoom Lens 3.95-7.51 (NP56ZL)

Accessories

Included	Remote Control Batteries Power Cord Lens hole cap	Optional	Adjustable Extension Column, 6" - 9" (AEC006009) Adjustable Extension Column, 12" - 18" (AEC012018) Adjustable Extension Column, 2' - 3' (AEC0203) Adjustable Extension Column, 3' - 5' (AEC0305) Ceiling Mount (IPJ2000CM) Black Input Terminal Cover (NP13CV-B) White Input Terminal Cover (NP13CV-W) 0.53-0.65:1 Short Throw Zoom Lens [lens shift] (NP51ZL) 0.63-0.85 Short Throw Zoom Lens [lens shift] (NP52ZL) 0.86-1.25 Short Throw Zoom Lens [lens shift] (NP53ZL) 1.24-2.01:1 Motorized Zoom Lens (NP54ZL) 1.98-3.95 Long Throw Zoom Lens [lens shift] (NP55ZL) 3.95-7.51 Ultra Long Throw Zoom Lens [lens shift] (NP56ZL) Replacement Remote (RMT-PJ40)
