Sharp 55" PN-LM551 AQUOS BOARD interactive displays

Sale price $1,926.00 Regular price $2,529.00
Shipping calculated at checkout.
Sharp  |  SKU: PN-LM551

Shipping Availability*

Free Ground Shipping on Most Orders Over $250.00

Free Shipping No Extra Costs*
Easy Returns Return with Ease
Secure Payments Data is Encrypted
Free Shipping No Extra Costs*
Easy Returns Return with Ease
Secure Checkout data is encrypted

The SHARP PN-LM551 AQUOS BOARD® interactive displays combines genuine 4K Ultra-HD resolution and an intuitive “Pen-on-Paper” user experience. The single USB-C connector makes it so simple to walk into a room, plug in your device and start working together straightaway. The PN-LM series AQUOS BOARD interactive displays also feature an integrated controller with whiteboard, overlay and wireless functionality to help enhance your productivity.

Features

  • 55" Class (54.6” diagonal) Screen Size
  • Brilliant Ultra-HD (3,840 x 2,160) Direct Lit LCD Display
  • 20–Point IR touch screen
  • Arm® Cortex®A73x4 2.3Ghz+Arm® Cortex®A53x4 2.0Ghz (octo-core)
  • 500 cd/m2 Brightness; 5,000:1 Contrast Ratio
  • EnergyStar 8.0 Certified
  • Built-in 10W per Channel Stereo Audio System
  • 5-Year Limited Warranty

Specs

Display
Panel Technology TFT LCD
Viewable Image Size 55"
Aspect Ratio 16:9
Native Resolution 3840x2160
Supported Resolutions 640 × 480, 800 × 600, 1024 × 768, 1280 × 960, 1280 × 1024, 1360 × 768, 1440 × 900, 1680 × 1050, 1280 × 720, 1920 × 1080, 3840 × 2160, 4096 x 2160, 720 x 400, 4096 x 2160p, 3840 x 2160p, 1920 x 1080p, 1920 x 1080i, 1280 x 720p, 720 x 576p, 720 x 480p, 640 x 480p, 720(1440) × 576i, 720(1440) × 480i
Pixel Pitch 0.315 mm
Backlight Type LED Direct-lit
Brightness (typical) 450 cd/m2
Brightness (maximum) 500 cd/m2
Contrast Ratio (typical/Dynamic) 5000:1
Viewing Angle 178° right/left/up/down (contrast ratio ≥ 10)
Refresh Rate 60Hz
Active Screen Area (W x H) 47.6" x 26.8"
Orientation Landscape/Portrait(counterclockwise)/Backward 0-45 degrees
Displayable Colors 1.07 billion
Synchronization Range
Horizontal (Analog/Digital) Digital 31.5kHz-135 kHz
Vertical 24Hz-70Hz
Input Signal
Video Analog RGB (0.7 Vp-p) [75Ω]
Sync Horizontal/vertical separation (TTL: positive/negative)
Signal Compatibility
PC Signal Compatibility Yes
Macintosh Signal Compatibility Yes
Video Analog RGB (0.7 Vp-p) [75Ω]
Sync Horizontal/vertical separation (TTL: positive/negative)
External Control LAN In/Out and RS232 In - Full external control capabilities
Connectivity - Input Terminals
Digital HDMI x3 (HDCP2.3, CEC, (HDMI3) ARC),USB type-C x1 *(DisplayPort 1.4) Alt mode, HD
Audio 3.5mm mini stereo jack
External Control RS-232C x1, LAN (10Base-T/100BaseTX) x1
Data USB (3.2 compliant) (Type A) x 2, USB (3.0 compliant) (Type B) x 1, USB (2.0 compliant) (Type A)
Connectivity - Output Terminals
Digital HDMI x1
Audio 3.5mm-diameter stereo mini jack x 1
Power Consumption (typical)
On 145W
ECO Mode Standby 0.5W
Network Standby 0.5W
Power Consumption (max) 230 W
Power Savings Mode 0.5 W
Physical Specifications
Bezel Width (Left/Right, Top/Bottom) 0.59 in./0.59 in., 0.59 in./0.59 in. : 15 mm/15 mm, 15 mm/15 mm
Dimensions (with stand) (WxHxD) 49.8" W x 2.9" D x 28.9" H
Shipping 55.51" W x 7.28" D x 34.84" H
Net Weight (with stand) 72.8 lbs.
Net Weight (without stand) 72.8 lbs. / 33 kg.
VESA Hole Configuration 400 x 400mm (M6 x 4-hole)
Environmental Conditions
Operating Temperature 41°F to 95°F (5°C to 35°C)
Operating Humidity 20% to 80% (no condensation)

Limited Warranty (Parts & Labor)

5 years

Additional Features

  • 4K Resolution
  • 4K Ready
  • 60 Hz LED Frame Rate
  • Built-In Speakers
  • LED Backlight
  • Power Management
  • Wired Network Connection
  • LAN control capability
  • Pen-on-paper®
  • Contrast Ratio (5000:1)

Optical

Display Technology
TFT LCD

Accessories

Included:

  • AC power cord:1
  • Remote control unit:1
  • Remote control unit battery (AAA size) : 2
  • Setup manual:1
  • Blank sticker(cover SHARP logo):1
  • Cable clamp:3
  • Camera mount:1
  • Camera mount screw:1
  • USB cable:1
  • Touch pen:2

Third Party:

  • Shuttle PN-SPCi7W11A signage PC
  • Shuttle PN-SPCi5W11A signage PC
  • Airserver ASC300 Universal Screen Mirror Solution
  • EverPro EP31605SH 5 Meter USB Type C cable

Cooling Method

Fanless - Convection
