Sharp NP-PA1505UL 15,000-lumen Professional Installation Projector w/ 4k support (No Lens)

Authorized Dealer

$23,228.00 $29,035.00

Shipping calculated at checkout.

Sharp | SKU: NP-PA1505UL-B

Color: Black

Product variants

Shipping Now*

Free Ground Shipping over $250.00

NEC's PA1505UL is a 14,000-lumen (Center: 15,000lm) LCD laser projector with advanced professional installation features for higher education and corporate users. With its multitude of digital inputs, connection to any computer or high definition device is possible. Enjoy design and installation flexibility with a complete line of optional motorized lenses (lens shift, focus and zoom), roll free installation capabilities. The HDBaseT input provides a single connection for uncompressed full HD digital video, audio, ethernet power and various control signals. HDBaseT Repeater allows cascading of the signal for edge-blending or stacking applications.

Features

4K Ready - Display stunning 4K 60P content using NEC’s proprietary high performance video processing/scaling chip from “Ultra HD Blu-ray” and “4K TV broadcasting” without the loss of critical details.
Learning of basic control of competitors product reducing the need for reprogramming of a control system. (call Sharp for complete list)
Integrated software applications such as AMX Beacon, Crestron Roomview, Extron XTP and PJ link allow for complete interactivity and control.
14,000-lumen (Center: 15,000lm) brightness provides brilliant images in most high ambient lighting situations.
ProAssist™ is software for controlling the projector and adjusting the projected image on the screen from a computer via a network. It allows necessary adjustments to be carried out easily when combining several projectors together to project a large screen in a classroom, meeting room, auditorium or other large space.

Specs

Display

Aspect Ratio	16X10	Screen Resolution	WUXGA 1920x1200
Maximum Resolution	4K 4096 x 2160	Brightness (typical)	14000 Lumens
Brightness (maximum)	15000 Center Lumens	Contrast Ratio (typical)	3,000,000:1 (with Dynamic Contrast)

Synchronization Range

Horizontal (Analog/Digital)	24-153kHz	Vertical	50-120Hz

Signal Compatibility/Connectivity

Supported Video Standards	NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM	SD/HD Video Signal Compatibility	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 4K
PC Signal Compatibility	VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA, Quad HD	Macintosh Signal Compatibility	Yes
Sync Compatibility	Separate Sync / Composite Sync / Sync on G	External Control	RS-232, IR, Wired Remote, HDBaseT, DDC/CI, RJ-45, USB (USB 2.0)
Input Terminals RGB1(digital): HDMI (V2.0) w/HDCP (V1.4/2.2) RGB2(digital): HDMI (V2.0) w/HDCP (V1.4/2.2) RGB3(digital): HDBaseT w/HDCP (V1.4/2.2) RGB4(digital): 3G SDI (SMPTE ST 424M / SMPTE 292M)		Output Terminals Audio Out: Stereo Mini Jack

Power Consumption (typical)

On	960W / 855W / 0.4W / 0.15W (Normal/Silent Mode/Network Standby/Standby)	Input Current	11.6A - 5.1A
Power Requirements	100-240V AC, 50/60 Hz

Physical Specifications

Dimensions (WxHxD) Product: 23.6 x 9.4 x 19.3 in. / 599 x 238 x 490 mm External: 23.6 x 9.4 x 19.3 in. / 599 x 238 x 490 mm Shipping: 29.1 x 15.0 x 24.8 in. / 739 x 382 x 629 mm		Weight Net Weight: 63.3 lbs. / 28.7 kg Shipping: 78.3 lbs. / 35.5 kg

Environmental Conditions

Operating Temperature	32-113°F / 0-45°C	Operating Humidity	20 to 80% Humidity (Non-Condensing)
Operating Altitude	0 to 2600 m (8,500 ft)	Storage Temperature	14-122°F / -10 50°C
Storage Humidity	20% - 80% (non-condensing)	Storage Altitude	0-12,000m / 0-39,370ft (above sea level)
