The Planar URW105 105" 5K 21:9 Ultra-Wide Touchscreen LED Display is a 500 nits bright LCD display capable of 24/7 operation and is ideally sized to suit the most popular unified communications and video collaboration platforms such as Microsoft Teams with its Front Row layout. In addition to being an ideal collaboration display, the ultra-wide 21:9 aspect ratio of the UltraRes W series is perfect for native cinematic playback. With built-in scheduling, monitoring, control system support, and the ability to display in portrait or landscape orientation, the URW105 is also a great choice for dynamic digital signage. Additionally, you can view two input sources at once with dual layout or picture-in-picture. The URW105 is TAA compliant with no wireless function or open-source OS, making it secure for government applications.
- IR remote included
- RS-232 control capable
- RJ45 LAN network connection
- HDMI-CEC
- Optical and 3.5mm audio outputs
- Built-in 15W stereo speakers
- Fanless design for quiet operation
Features
- 5K (5120 x 2160) Native Resolution
- HDR10 Compatible
- Direct-lit LED LCD Panel
- Crestron & Q-SYS Compatible
- 2 x DisplayPort | 2 x HDMI | 1 x USB-C
- 1200:1 Static Contrast Ratio
- 500 nits Brightness | 25% Haze Level
- Digital Signage Support
- 24/7 Duty Cycle | Portrait & Landscape
- TAA Compliant
Specs
Planar Systems URW105 Specs
Size | 105" |
Panel Type | LCD |
Aspect Ratio | 21:9 |
Display Orientation | Landscape, Portrait |
Resolution | 5120 x 2160 |
Maximum Brightness | 500 nits / cd/m2 |
Lighting System | Direct LED |
HDR Compatibility | HDR10 |
Contrast Ratio | 1200:1 |
Dynamic Contrast Ratio | 40,000:1 |
Response Time | 8 ms |
Refresh Rate | 60 Hz |
Bit Depth / Color Support | 10-Bit (1.07 Billion Colors) |
Color Gamut | 88% NTSC |
Viewing Angle (H x V) | 178 x 178° |
Screen Area | 96.4 x 40.7" / 2449.2 x 1033.6 mm |
Dot Pitch | 0.479 x 0.479 mm |
Pixels Per Inch (ppi) | 53 ppi |
Finish | Anti-Glare / Matte |
Haze Level | 25% |
TV Tuner | No |
Inputs | 2 x DisplayPort (1.4) 2 x HDMI (2.1) |
Outputs | 1 x DisplayPort 1 x 1/8" / 3.5 mm (Analog Audio) 1 x TOSLINK Optical (Digital Audio) |
HDCP Support | Yes, Version 2.2 |
Wireless | None |
NFC | No |
USB I/O | 1 x USB-C Unspecified Version (Audio/Video) 4 x USB-A Unspecified Version (Audio/Photo/Video/Control/Power) 2 x USB-B Unspecified Version 1 x USB-A Unspecified Version (Service) |
Ethernet I/O | 1 x RJ45 (Unspecified Ethernet) |
Other I/O | 1 x 1/8" / 3.5 mm IR Input 1 x DE-9/DB-9 Serial (RS-232C) Control Input |
Number of OPS/Expansion Slots | 1 |
Ambient Light Sensor | Yes |
Multi-Input Support (PIP/PBP) | Picture-in-Picture (PIP), Picture-by-Picture (PBP) |
Built-In Speakers | Yes, 2 x 15 W |
Speaker Configuration | 2-Channel |
OS Compatibility | Windows 10 Windows 11 macOS Linux *As of June, 2023: Check with manufacturer for the most up-to-date compatibility |
Mobile App Compatible | No *As of June, 2023: Check with manufacturer for the most up-to-date compatibility |
Media Card Reader | None |
Built-In Mic | No |
Supported Languages | English French German Italian Japanese Portuguese Simplified Chinese Spanish Traditional Chinese |
Operating Temperature | 32 to 95°F / 0 to 35°C |
Operating Humidity | 20 to 85% (Non-Condensing) |
Operating Altitude | 9842' / 3000 m |
Power Consumption | Typical: 372.0 W Standby: < 0.5 W |
AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
Power Adapter Type | Internal |
Certifications | FCC Class A, CE, cTUVus, RoHS *as per Manufacturer |
Mounting-Hole Pattern | 1000 x 600 mm |
Lighting Lifespan | 30000 Hours |
Material of Construction | Glass, Metal |
Environmental Protection | None |
IK Rating | None |
Lock Slot | No |
Bezel Thickness | 27.5 mm |
Duty Cycle | 24 Hours / 7 Days |
Dimensions | 98.7 x 43 x 3.5" / 2507.5 x 1091.2 x 88.6 mm |
Weight | 158.7 lb / 72 kg |
