Planar Simplicity P Series SLP86 4K LCD Display, 86in diagonal
The Planar® Simplicity™ P Series SLP86 is a 86" 4K LCD display for landscape or portrait digital signage. It affordably incorporates media playback, cybersecurity mitigation, 4K @ 60Hz support, ENERGY STAR® efficiency and 24x7 commercial functionality. Its elegant design with a narrow, logo-free bezel and slim profile delivers an ideal display for digital signage applications requiring continuous 24x7 operation including wayfinding, emergency messaging, advertising and menu boards.
Features
Always-On Reliability
Displays are designed for mission-critical environments where displays need to withstand extended or continuous operation and deliver exceptional performance day and night.
Landscape or Portrait
Displays can be mounted in either landscape or portrait orientation, opening the door to a wider array of deployment environments and applications, and enabling greater creativity in content development.
Interactive Functionality, Standard
With integrated multi-point touch models, Planar large format LCD displays support a range of interactive applications including collaboration, presentation, whiteboarding and annotation.
Cybersecurity
Displays have been designed to mitigate potential cybersecurity threats. They meet the stringent European Telecommunications Standard Institute (ETSI) EN 303 645 cybersecurity standard.
Energy Efficiency
Displays have earned the U.S. government's ENERGY STAR® label identifying them as a solution that saves operation costs and electricity.
On Your Schedule
Automated scheduling for power and media playback ensures displays operate only when needed, saving energy and enhancing efficiency.
Specs
| Specification: | Detail: |
|---|---|
| Product Name | SLP86 |
| Planar Part Number | 998-3930-00 |
| Display Resolution | Ultra HD (3840 x 2160) |
| Screen Size | 86 in. (diagonal) |
| Aspect Ratio | 16:9 |
| Display Technology | Direct-lit LED LCD |
| Haze | 22% |
| Surface Treatment | AG |
| Display Active Area | 74.7” x 42.1” (1898.0mm x 1069.0mm) |
| Viewing Angle (typ) | 178° |
| Backlight | LED |
| Backlight life (1/2 brightness) | 30,000 hrs (min) |
| Brightness (typ) | 500 nits |
| Response Time (typ) | 8 ms |
| Frame Rate | 60Hz |
| Contrast Ratio (typ) | 1200:1 |
| Pixel Pitch | 0.494mm x 0.494mm |
| Color Gamut | 72% NTSC |
| Display Color | >1 billion colors. Full 10 bit data path |
| External Connections | HDMI® x 2 (HDCP 2.2), USB-C x 1, VGA x 1, USB 3.0 x1, USB 2.0 x1, MicroSD |
| Modes | 3840x2160 @ 24/25/30/60Hz; 480p, 576p, 720p @ 50/60 Hz; 1080p @ 50/60Hz; 1080i @ 50/60 Hz |
| Display Control | IR, RS-232, LAN, HDMI-CEC, Keypad |
| Cabinet Dimensions (W x H x D) | 75.9" x 43.3" x 2.7" (1929.1mm x 1100.0mm x 69.5mm) |
| Cabinet Dimensions with Handles (W x H x D) | 75.9" x 43.3" x 3.8" (1929.1mm x 1100.0mm x 95.3mm) |
| Orientation | Landscape/Portrait |
| Bezel Width | 0.6" (15.5mm) |
| Display Edge to Active Area | 1.1" (26.7mm) |
| Weight | 103.9 lbs (47.3 kg) |
| Weight (Shipping) | 139.4 lbs (63.2 kg) |
| Audio Input | PC Line In |
| Audio Output | PC Line Out, S/PDIF |
| Speakers | 10W x 2 built-in |
| Enclosure | Metal rear enclosure |
| Mounting | VESA: 600mm x 400mm |
| Fanless | Yes |
| Line Voltage | 100-240V; 50/60Hz |
| Power Consumption (typ) | 260W (standby: <0.5W) |
| Operating Temperature | 0° to +40°C (32° to 104°F) up to 3000m |
| Humidity | 20 - 85% RH (non-condensing) |
| Options / Features | Media file playback via USB, MicroSD, internal storage, web page and embedded cloud-based content app (requires subscription). Logo-free bezel, logo-free bezel, lockable rear keypad. |
| Operating System | Proprietary OS based on Android 10.0. Google Play and installation of third-party apps are not supported by Planar. |
| Storage | 32GB (10.5GB available) |
| Approvals | FCC Class A, cTUVus, CE, RoHS, EN 303 645 |
| ENERGY STAR® Certified | Yes |
| Cyber Security | EN 303 645 certified |
| Security | No WiFi, Secure Shell (SSH) protocol, EN 303 645 certified |
| Warranty | 3 years Advance Exchange |
| Recommended Usage | Up to 24x7 |
| In the Box | SLP86 display, C14 connector US power cord - 1.8m, C14 connector EU power cord - 1.8m, HDMI cable - 1.8m, USB-C cable 1.8m, RS-232 cable, IR cable, remote control, cable clamps, Quick Start Guide |
| UPC | 8 10069 81155 0 |
| HDMI® | Planar utilizes HDMI® standards in this product. The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. |
