Liberty AV 24-4P-P-L6-EN-BLU 1000 ft Reel of Cat6 U/UTP EN Series 23 AWG 4 Pair Unshielded Cable

$665.00

Shipping calculated at checkout.

Liberty AV | SKU: 24-4P-P-L6-EN-BLU

Shipping Availability*

Free Ground Shipping on Most Orders Over $250.00

Looking for the best price or just need expert advise?
Give us a call at 1-888-230-3661 or LiveChat below.
Purchasing 1 or 100, there may be greater savings beyond the advertised price.

Liberty AV Solutions' 24-4P-P-L6-EN-BLU is a 1000 ft reel of Cat 6 U/UTP EN Series 23 AWG 4-Pair unshielded cable that features solid annealed bare copper conductors, Fluoropolymer insulation, and a Plenum-rated PVC jacket.

Applications:

Horizontal LAN 10/100/1000BaseT Ethernet
Audio, Video, Infrared, IP Control
Balun infrastructure, Voice, Voice over IP
PoE, HDBaseT, Analog and Digital Media

Liberty AV Solutions 24-4P-P-L6-EN-BLU Features:

4 pairs twisted in varying lays and cabled
TIA/EIA-568-C Category 6 and tested to 550 MHz
NEC CMP, CEC CMP FT6, RoHS compliant

Liberty AV Features:

23 AWG solid bare copper conductors
HDPE, high-density polyethylene insulation
Color striping on white conductors
Varying lay twisted pairs cabled on a common axis
Ripcord under the jacket
FR-PVC, flame rated polyvinyl chloride jacket
Tested to 550 MHz with a positive ACR spec to 550 MHz
Third party (UL, ETL) certified to category 6 performance
NEC rated CMR, CEC rated CMR, CMG FT4, RoHS compliant

Liberty AV Specifications:

Gauge: 23 AWG
Material: Solid annealed bare copper
Diameter: 0.0226" | 0.574mm
DC Resistance: ≤ 20.12 Ω / 1000’ | 65.99 Ω/KM
DCR Unbalance: ≤ 5.0%
Capacitance: 14.0 pF/FT | 45.9 pF/M
Impedance: 100 ± 15 Ω
Propagation Delay (Skew): 45ns/100m MAX
Velocity of Propagation: 71%
Voltage Rating: 300V
Pair to Ground Capacitance Unbalance: ≤ 330 pF/100M
Maximum Current: 1.4A@25°C
Material: Fluorinated ethylene propylene
Wall Thickness: 0.008" | 0.20mm
Diameter: 0.0386" | 0.981mm
ANSI/TIA-568-C Category 6
NEC: CMP 75°C
CEC: CMP FT6 60°C
EU RoHS-2 2011/65/EU Compliant
Pair 1: Orange, White/orange stripe
Pair 2: Blue, White/blue stripe
Pair 3: Green, White/green stripe
Pair 4: Brown, White/brown stripe
Pairs twisted in varying lay lengths
Each pair in a fluoropolymer X separator interstice
Installation Pull Tension: 25 Lbs | 111 N
Bend Radius (Unloaded): 2.20" | 56mm
Bend Radius (Loaded): 4.40" | 112mm
Plenum cable should be conditioned at room temperature for 24 hours prior to installation and never installed below 32°F | 0°C ambient temperature
Plenum rated polyvinyl chloride
Colors: Blue, White, Green, Yellow
Wall Thickness: 0.019" | 0.483mm
Diameter: 0.220" | 5.59mm
Final Outside Diameter (inches): 0.22
