INOGENI SHARE2 Dual Video USB 3.1 Gen 1 Capture Device
Mix 2 HDMI/DVI cameras to USB 3.0 - SHARE2
INOGENI’s easy and versatile SHARE2 Camera Mixer provides Picture-In-Picture in one video flow. Create interactive presentations for collaborative meetings and HyFlex classrooms.
- 2 HDMI cameras mixer into a single USB 3.0 interface
- Engage a dynamic presentation and easily switch up to 14 mix setup videos
- Change camera and video configuration without cutting the flow of your presentation
- Ideal for remote education, collaborative meetings, webinars or live streaming
- Output: Uncompressed video on USB 3.0 or MJPEG on USB 2.0
- Audio I/O and mixer via the INOGENI Control App
- Controllable by LAN & RS-232
- Cost-effective solution that is reliable and simple to install and connect (no driver required)
- Compact and robust design with its aluminium enclosure
- Designed and manufactured in Canada
How it works
The SHARE2 Dual HDMI/DVI to USB 3.0 professional camera mixer can be controlled by an application on the host side using our LAN or RS-232 interfaces. You can also use the keypad on the top of the device to control it manually.
You can use the camera mixer feature of the SHARE2 to embed your two video sources into one single stream. This feature can be an important asset for you if your application only supports one video interface, like Teams®, Zoom®, Webex®, GoToMeeting® and all video conferencing applications.
Easy push-button to switch easily up to 14 mix setup videos
Features
The SHARE2 Dual HDMI/DVI to USB 3.0 professional camera mixer offers an array of features for a smooth and seamless experience.
- Control interface: LAN, RS-232, USB (Get the software upgrade: Crestron Serial & IP modules)
- Local and remote keypad: REMOTE User Guide
- HDMI, DVI, VGA or CVBS video input connectors; VGA and CVBS are available using an adapter
- Unbalanced, line level stereo audio support
- Digital Fluid technology: Internal frame buffers maximize frame rate with any host
- Hardware-based color space and sampling conversion
- Automatic scaling and frame rate conversion
- Customizable video processing functions
- Supports multiple devices on the same host
- Device configuration via the INOGENI Control App
- Firmware upgrade available via the INOGENI Control App
- Compatible with Barco ClickShare Conference
Specs
INOGENI SHARE 2 Dual Specs
| Video Input 1 | 1 x HDMI 1080p, 720p, 1080i, 480p, 576p, 1920x1200, 1280x1024, 1280x960, 1024x768, 800x600, 640x480 |
| Video Input 2 | 1 x DVI-I (Digital + Analog) DVI: 1080p, 720p, 1080i, 480p, 576p, 1920x1200, 1280x1024, 1280x960, 1024x768, 800x600, 640x480 VGA: 1080p, 720p, 480p, 576p, 1920x1200, 1680x1050, 1400x1050, 1600x1200, 1280x1024, 1360x768, 1280x768, 1280x800, 1024x768, 800x600, 640x480 or 1 x CVBS 480i, 576i |
| Frame Rates | Up to 60 Hz, all formats |
| Color Space | RGB, YCbCr, 4:4:4, and 4:2:2 |
| Sampling Rate | 165 MHz |
| Analog Audio Input | Analog stereo, line level, 3.5 mm jack |
| Analog Audio Output | Analog stereo, line level, 3.5 mm jack |
| RS232 | Via RJ45 port |
| HDCP | The device will not decrypt BD/DVD movies, satellite/cable receivers, or other encrypted sources |
| Mixer | The Mixer feature can be controlled by the following interfaces: panel control buttons, RS-232, optional INOGENI REMOTE, or HID (Human Interface Device) via USB connection |
| Connector | 1 x USB 3.0 |
| Color Space | YCbCr (YUY2) 4:2:2 8-bit |
| Video Scaler | Automatic hardware based |
| Color Space Conversion | Automatic hardware based |
| Sampling Conversion | Automatic hardware based |
| Frame Rate Conversion | Automatic hardware based |
| Audio Input | 2-channel LPCM 48 kHz audio from line input or embedded in HDMI |
| Audio Output | 2-channel LPCM 48 kHz audio line level |
| USB Expansion | 2 x extra USB 3.0 ports for expansion purposes (The devices connected will appear to the host) |
| USB Bandwidth | No USB bandwidth limitation |
| Operating Systems | No driver installation required Windows 7 and above (32-/64-bit) OS X 10.10 and above Linux (kernel v2.6.38) and above Android |
| Host Requirements | USB 3.0 port Minimum 4 GB RAM Intel Core i5 Graphic card with dedicated memory |
| Motherboard | Compatible with all motherboards Intel, Renesas, ASMedia, and Fresco Logic |
| Cameras Supported | Cameras and camcorders with an HDMI, DVI, VGA, or CVBS output |
| Software Compatibility | UVC-compliant; runs with all software compatible to DirectShow, AVFoundation, and V4L2 |
| Power | 12 V, 500 mA |
| Operating Temperature | 32 to 113°F (0 to 45°C) |
| Storage Temperature | -40 to 221°F (-40 to 105°C) |
| Relative Humidity | 0 to 90% non-condensing |
| Dimensions | 7.3 x 4.4 x 1.2" (18.5 x 11.2 x 3 cm) |
| Weight | 1 lb (466 g) |
| Package Weight | 2.7 lb |
| Box Dimensions (LxWxH) | 8.85 x 6.95 x 3.6" |
