Crestron CEN-SWPOE-5AC 5-Port PoE Network Switch
The CEN-SWPOE‑5AC is a 5-port unmanaged Gigabit Ethernet switch that provides Power over Ethernet (PoE) from four of its ports. Power over Ethernet provides a one-wire solution for connecting Crestron touch screens, gateways, and other devices, delivering power and data over a single CAT5/6 network cable. Auto-negotiating and auto MDI/MDIX allows the ports to negotiate device connection types. All five ports are Gigabit capable to ensure maximum bandwidth for multimedia and critical control data.
Using the CEN-SWPOE‑5AC, there is no need to install a separate power supply at each networked device location. The CEN-SWPOE‑5AC can simply be mounted at a convenient location on a wall or in an equipment rack, providing a single power source for four separate 802.3af/at (up to 30 W each port) compliant PoE powered devices. Non-PoE devices may also be connected to any port on the CEN-SWPOE‑5AC without risk of damage to either component.
Features
- 5-port unmanaged Ethernet switch
- All ports support 1000BASE-T Gigabit Ethernet
- Provides PoE and PoE+ (802.3af/at) on four ports
- Auto-negotiating and auto MDI/MDIX
- Rugged metal enclosure
- Mounting options for flat surface or ceiling, junction box, and DIN rail applications
- Supports lighting control for room-to-room communication
Specs
| Ethernet | |
| Ports | (5) 100BASE-TX/1000BASE-T |
| Ethernet Network Standards | IEEE 802.3, 802.3u, 802.3ab, 802.3x, & 802.3af /at |
| Transmission Method | Store-and-forward |
| Indicators | |
| PoE 1 – 4 | (4) green LEDs, indicate a PoE powered device is connected to each corresponding Ethernet port |
| Uplink | (1) green LED and (1) amber LED; indicate Ethernet link status, speed, and activity at the Uplink port |
| 1 – 4 | (1) green LED and (1) amber LED per each of (4) Ethernet ports; indicate Ethernet link status, speed, and activity at each corresponding port |
| Power | (1) green LED, indicates operating system |
| Connectors | |
| Uplink | (1) 8-wire RJ-45, female; 100BASE-TX/1000BASE-T Ethernet port |
| 1 – 2 | (2) 8-wire RJ-45, female; 100BASE-TX/1000BASE-T Ethernet ports and PoE+ Power Sourcing Equipment (PSE) outputs; Ports 1 and 2: 30 W (max) |
| 3 – 4 | (2) 8-wire RJ-45, female; 100BASE-TX/1000BASE-T Ethernet ports and PoE Power Sourcing Equipment (PSE) outputs; Ports 3 and 4: 15.4 W |
| Power Requirements | |
| Input Range | 100-277VAC 50/60Hz |
| Input Current | 2A @ 115VAC, 1A @ 277VAC max |
| Environmental | |
| Temperature | 32° to 104°F (0° to 40°C) |
| Humidity | 10% to 90% RH (noncondensing) |
| Heat Dissipation | 10 BTU/hour |
| Construction | |
| Chassis | Metal, black finish, with (2) integral mounting flanges |
| Mounting | Freestanding, surface mount, ceiling wall box, DIN 49073, DIN Rail or attach to a single rack rail |
| Dimensions | |
| Height | 4.72 in. (120 mm) |
| Width | 7.34 in. (187 mm) |
| Depth | 1.85 in. (47 mm) |
