QSC PL-DC12-YM Yoke Mount for PL-DC12

Yoke Mount Bracket for PL-DC12 Loudspeakers

Heavy-Duty Yoke Mount for Secure, Versatile Loudspeaker Suspension

Designed specifically for the PL-DC12 loudspeaker, this premium Yoke Mount Bracket enables secure, adaptable mounting in both fixed and temporary AV installations. Built for performance in demanding commercial environments, the bracket features high-strength galvanized construction, flexible speaker positioning, and universal truss compatibility—ideal for venues requiring precise audio coverage and robust rigging support.

Key Features and Benefits

• High-Strength Construction
  Fabricated from 3.4 mm thick galvanized cold-rolled steel (CRS) to ensure maximum structural stability under load.
• Durability and Environmental Resistance
  Finished with a powder coating rated for 1000-hour UV exposure and 200-hour salt spray testing, providing long-lasting corrosion resistance in indoor and semi-exposed environments.
• Dual Loudspeaker Mounting Options
  Includes a quick setup slot and an additional fixed hole to enable more compact positioning when space is limited.
• Vibration Isolation
  Comes with two round rubber spacers to be positioned between the loudspeaker and the yoke, minimizing vibration transmission and ensuring clean audio reproduction.
• Universal Rigging Compatibility
  Features a central 13 mm hole for clamp mounting and three standardized mounting patterns to support both US and European trusses:
• 240 mm spacing (11 × 7 mm oblong holes)
• 386.4 mm spacing
• 589.6 mm spacing (7 × 20 mm slot holes)
• Traceability Identifier
  Every bracket includes a unique part ID for tracking and inventory control, meeting industry quality assurance standards.

Ideal Applications

• Houses of Worship
• Theaters and Auditoriums
• Live Event Venues
• Corporate Conference Rooms
• Broadcast and Recording Studios
• Convention Centers
• Multipurpose AV Environments
• Government and Civic Spaces

Competitive Advantages

• Industrial Rigging Standards: Built-in truss compatibility for fast, safe rigging in professional environments.
• Dual Mounting Flexibility: Offers both quick-install and precision-fit options—ideal for varying venue geometries.
• Vibration-Reducing Design: Rubber spacers ensure clean sound performance and hardware longevity.
• Extreme Durability: Withstands harsh install conditions better than basic powder-coated mounts.
• Integration-Ready: Optimized for AV installers requiring traceability, safety, and quick deployment.
