Bluesound BCS300 Professional Network Streaming Ceiling Speaker

The BCS300 is a seamlessly integrated, all-in-one in-ceiling or hanging pendant speaker solution featuring a built-in music streamer and amplifier. Using power over ethernet technology, it efficiently delivers audio to its desired destination in a discreet and simplified manner, requiring only a single ethernet cable connection to deliver both power and network connection. Unlike traditional setups, this decentralized solution eliminates the need for an audio rack, functioning as an independent unit. Moreover, its flush mounted design allows it to seamlessly blend with any interior design or décor. Its high-performance build includes a UL 2043 plenum rating, fully certifying it for commercial installation. The optional pendant kit allows the BCS300 to be ceiling suspended and allows positioning of speakers at a lower height if there is nothing available to mount it at a typical height, especially in the case of exposed ceilings. Based on the award-winning BluOS multi-room platform, the BCS300 enables multi-zone control, speaker grouping and integrated networked music streaming from Bluesound Professional’s business music partners: SOUNDMACHINE, Qsic, Custom Channels, SiriusXM for Business and Tunify.

Features

• Full-range network streaming speaker system
• 3.5” LF driver and 1” HF driver
• 45Hz – 20kHz frequency range
• 003% THD+N at full rated power
• Maximum SPL of 102db (PoE+)
• DSP providing equalization and other audio processing
• 2 x BCS300’s can pair in stereo configuration
• Flexible and unlimited grouping of zones within a BluOS system
• Integration with local network content storage
• Integration with many streaming services including Custom Channels, SoundMachine, Qsic, SiriusXM Music for Business, Spotify, Tidal and Qobuz
• Integration with a wide variety of internet radio platforms
• PC/Mac, iOS/Android and third-party control
• Security preventing unauthorized control
• Specialist Bluesound Professional control panels
• Support of hi-res audio up to 192kHz/24 bit
• Support of MQA content
• Streaming via ethernet for increased reliability with PoE+ providing one-wire connectivity and power
• Slim profile requires only 5 inches of depth
• UL 2043 Plenum Rated
• White magnetic grille included and optional black grille available
• Available in Black with White Grille
• Optional BCS Pendant Kit available in Black or White

Specs

• Audio
  • Supported File Formats: MP3, AAC, WMA, OGG, WMA-L, ALAC, OPUS
  • Hi-Res Formats: FLAC, MOA, WAV, AIFF
  • Native Sampling Rates: 32-192kHz
  • Bit Depths: 16-24
• Performance
  • Frequency Response: -10db 45Hz-20kHz
  • Distortion: THD+N-0.030% (20hz-20khz at Rated Power)
  • Power Output: 23 Watts total system power at 0.030% THD
  • Speakers: 1x 89mm (3.5"), Woofer
  • Supported Operating Systems: 1x 25mm (1"), Tweeter. Plays music from network shares on the following desktop operating systems: Microsoft, Windows 2000 and newer and Apple Macintosh 7 and newer.
  • Free Internet Radio: TuneIn Radio, iHeartRadio, Calm Radio, Radio Paradise, LiveXLive
  • Supported Cloud Services: SoundMachine, Tunify, Custom Channels, SiriusXM for Business, Spotify, Tidal, Amazon, Deezer, Qobuz, TuneIn, Radio.com and many others
  • Integration Partners: Control4, RTI, Crestron, URC, QSYS, push, ELAN, Lutron
  • Album Art: JPG
• Connectivity
  • Network: Ethernet RJ45, 100BaseT
  • Power: PoE+ IEEE 802.3 at Type 2-30W
  • User Interface: User Interface
  • Mobile Operating System: BluOS-Free Android and IOS App Available Online at GooglePlay and Apple App Store
• General
  • Processor: ARM® CORTEX™ A53 1.8GHz
  • Unit Weight: 123kg/2.7 lbs
