Atlas Sound VT-157UCN Voice/Tone Recessed Compression Driver Speaker with 15-Watt 70V Transformer (Gray)

Sale price $178.99 Regular price $221.99
Shipping calculated at checkout.
AtlasIED  |  SKU: VT-157UCN

Shipping Availability*

Free Ground Shipping on Most Orders Over $250.00

Free Shipping No Extra Costs*
Easy Returns Return with Ease
Secure Payments Data is Encrypted
Free Shipping No Extra Costs*
Easy Returns Return with Ease
Secure Checkout data is encrypted
70.7V/15W surface mount compression driver loudspeaker, through proven performance, patented VT/VTF Series have earned worldwide acclaim for service reliability. These cost-effective units offer compact size, functional flexibility, optimum intelligibility, effective sound distribution, and high-level output. All models contain a high efficiency compression driver with maximum acoustic conversion efficiency. (A quality which reduces number of units needed to attain specified sound pressure levels and provides substantial savings in amplification-power requirements and labor costs.) Die-cast, water-sealed construction withstands vandalism, vermin, moisture, corrosion, and vibration during indoor or outdoor use. Selection includes a basic 8-ohm version and 70.7 or 25-volt transformer models with DC blocking capacitor (C) where noted. All models terminate via barrier strips. VT Series models are surface-mount units; VTF Series are flush-mount units for recessed installation. VT Series mounts standard 4" E.O. Boxes; VTF Series mount 4" or 4 11/16" SQ back boxes and require model AR or MR adapter rings respectively (order separately) Optional mounting accessories are offered including: indoor and outdoor enclosures, a bi-directional housing, adapter plates and rings.
Features
  • All Models Produce High Level Output, Optimum Intelligibility, and Effective Dispersion
  • Choose from Surface or Recessed Models in Red or Neutral Gray Finish
  • Durable, Die-Cast, Water-Sealed Housings Withstand Vandalism, Vermin, Moisture, Corrosion, and Vibration
  • Easy and Low Cost Installation Via Standard E.O. Boxes
  • Ideal for Reliable Voice/Tone Signaling in Public Area Emergency Communications and Heavy-Duty Industrial Applications
  • Model Produces High Level Output, Optimum Intelligibility, and Effective Dispersion
  • UL Certified, Safety Listed to UL1480
  • Patented Emergency Loudspeakers Available in 8-Ohm, 70.7V, and 25V Versions
  • Surface Models in Neutral Gray Finish
  • Units Meet or Exceed UL Standard 1480 for Fire Protective Signaling Systems when Used with Compatible Control Equipment
Specs
Frequency Response 600Hz - 5.5kHz
Sensitivity 96.9dB (1W/1m)
Power Taps 15, 8, 4, 2
Dispersion > 190° (- 6dB pt., 1 and 2 kHz octave bands)
Transformer 70.7 V
Height 6" (15.24 cm)
Depth 3 3/16" (8.09752 cm)
Shipping Weight 3.10 lbs (1.41 kgs)
Safety Listed 1480
