Image Sensor: |
1/2.8" STARVIS™ CMOS |
Effective Pixels: |
1920(H) x 1080(V), 2 Megapixels |
RAM/Rom: |
4GB/ 1GB |
Scanning System: |
Progressive |
Minimum Illumination: |
Color: 0.005 lux@F1.6 B/W: 0.0005 lux@F1.6 0 lux (IR light on) |
S/N Ratio: |
More than 55dB |
Illumination Distance: |
Distance up to 492ft (150m) |
Illumination On/Off Control: |
Auto / Manual |
Illumination LEDs: |
4 |
Camera Illumination Type: |
IR |
Lens |
Focal Length: |
4.8mm~120mm |
Max. Aperture: |
F1.6–F3.5 |
Angle of View: |
H: 58.5°–2.8°; V: 33.2°–1.5° |
Optical Zoom: |
25x |
Focus Control: |
Auto/Manual |
Close Focus Distance: |
0.33 ft–4.92 ft (0.1 m–1.5 m) |
DORI - Detect: |
5,292 ft |
DORI - Observe: |
2,119 ft |
DORI - Recognize: |
1,060 ft |
DORI - Identify: |
528 ft |
PTZ |
Pan/Tilt Range: |
Pan: 0° to 360° endless Tilt: –15° to +90°, auto flip 180° |
Manual Control Speed: |
Pan: 0.1°/s–300°/s; Tilt: 0.1°/s–200°/s |
Preset Speed: |
Pan: 240° /s; Tilt: 200° /s |
Presets: |
300 |
PTZ Mode: |
5 Pattern, 8 Tour, Auto Pan ,5 Scan |
Speed Setup: |
Human-oriented focal Length/ speed adaptation |
Power up Action: |
Auto restore to previous PTZ and lens status after power failure |
Idle Motion: |
Preset; Pattern; Tour; Scan |
Protocol: |
ICR-SD, Pelco-P/D (Auto-recognition) |
Intelligence |
IVS: |
Tripwire; intrusion |
Advanced Intelligent Functions: |
Perimeter Protection (Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast-moving) Intelligent Motion Detect 2.0, Face Detection, Video Metadata, People Counting, Auto Patrol |
Video |
Compression: |
Smart H.265+; H.265; Smart H.264+; H.264; H.264B; H.264H; MJPEG (Sub Stream 1) |
Streaming Capability: |
3 Streams |
Resolution: |
1080P(1920×1080)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×240) |
Frame Rate: |
Main stream: 1080p/1.3M/720p (1–25/30 fps) Sub stream1: D1/CIF (1–25/30 fps) Sub stream2: 1080p/1.3M/720p (1–25/30 fps) |
Bit Rate Control: |
CBR/VBR |
Bit Rate: |
H.265/H.264: 448K ~ 8192Kbps |
Day/Night: |
Auto(ICR) / Color / B/W |
Backlight Compensation: |
BLC / HLC / WDR(120dB) |
White Balance: |
Auto, ATW, Indoor, Outdoor, Manual |
Gain Control: |
Auto / Manual |
Noise Reduction: |
2D NR; 3D NR |
Flip: |
180° |
WDR: |
120dB |
Audio |
Compression: |
PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 |
Network |
Ethernet: |
RJ-45 (10Base-T/100Base-TX) |
Protocol: |
HTTP; HTTPS; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; IPv6; 802.1x; QoS; FTP; UPnP; ICMP; SNMP; SNMP v1/v2c/v3 (MIB-2); IGMP; ARP; RTCP; RTP; PPPoE; RTMP; TCP |
Interoperability: |
ONVIF (Profile S&G&T); CGI |
Streaming Method: |
Unicast / Multicast |
Max. User Access: |
20 (total bandwidth: 64 M) |
Edge Storage: |
FTP; Micro SD card (512 GB); NAS |
Web Viewer: |
IE, Chrome, Firefox, Safari |
Management Software: |
SmartICRSS, DSS |
Smart Phone: |
IOS, Android |
Interface |
Video Interface: |
1 port(BNC, 1.0V[p-p], 75Ω) |
Audio I/O: |
1/1 channel In/Out |
Alarm I/O: |
2/1 |
Factory Reset: |
Yes |
Memory Slot: |
Micro SD card (512 GB) |
Electrical |
Power Supply: |
24 VDC, 2.5 A (± 25%); PoE +(802.3at) |
Power Consumption: |
Basic: 13 W Max.: 22 W (illuminator + PTZ working) |
Environmental |
Operating Conditions: |
-40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH |
Ingress Protection: |
IP67 |
Vandal Resistance: |
IK10 |
